TT24B Earth and resistivity tester

STANDARD(S) :
50V CAT IV

USE : 4 in 1 : Earth / Resistivity / Coupling / Continuity / Possibility Adapted for the Industry and housing

SPECIFICATIONS :
3P and 4P method
Range resistivity : 0 to 100Ω
Measurement frequency : 41 to 512 Hz
DC resistance measurement 2 wires or 4 wires
Resistivity : Wenner and Schlumberger with automatic calculation
512 memory locations
USB communication
Delivered with 1 external mains charger, data export software + optical / USB communication lead, 5 operating manuals (one per language) on CD-ROM, 5 simplified operating manuals, each in a different language, 5 descriptive labels, each in a different language (earth kit not supplied)

ADVANTAGES :
• Multi-function tester.
• Measurements possible even with highly resistive soils
• Improved measurement quality due to high rejection of disturbance voltages
• Excellent accuracy and resolution
• Standard software for data recovery and processing of the results
