PENTA-POLE measure Telescopic insulating measuring stick

STANDARD(S) :
IEC 60855-1 / IEC 6213 ASTM F 1826 / ASTM F711

Use
The Penta-Pole measuring stick has measurement graduations (in mm) on each section allowing to easily measure any heights range from 3 m to 12 m.
Designed to be used on Middle Voltage overhead networks ( nominal voltage lower than 123 kV).

Technical specifications
Telescopic insulating stick composed of :
• 5 to 8 pentagonal shaped tubes compliant with standards IEC 62193 and ASTM F1826, each section has a measurement graduation in millimetre
• 1 foam cored upper tube, 28 mm in diameter, compliant with standards IEC 608551 and ASTM F711
• 1 base to protect the end of the stick
• 1 universal end fitting to fix multiple accessories and adapters

Advantages
• Ergonomically designed grip thanks to its pentagonal shape that fits the palm of the hand
• The pentagonal shape prevents the tubes rotating on each other
• Very lightweight stick : requires less effort during use
• Very good rigidity providing optimal control during your operations
• The sections are locked together automatically when the stick is extended by a large and very robust red button. Unlocking to retract the stick simply involves pressing the button, with no risk of trapping finger or gloves in the mechanism

PPOL5/060MU / Number of element 5 / Folded length (m) 1,58 / Length unfolded (m) 6,3 / Telescopic insulating measuring pole 5 elements / Cover HPPOLE/170 / Max operating voltage cond. dry 420 kV
PPOL6/075MU / Number of element 6 / Folded length (m) 1,65 / Length unfolded (m) 7,7 / Telescopic insulating measuring pole 6 elements / Cover HPPOLE/170 / Max operating voltage cond. dry 525 kV
PPOL7/090MU / Number of element 7 / Folded length (m) 1,71 / Length unfolded (m) 9,1 / Telescopic insulating measuring pole 7 elements / Cover HPPOLE/190 / Max operating voltage cond. dry 765 kV
PPOL8/105MU / Number of element 8 / Folded length (m) 1,78 / Length unfolded (m) 10,6 / Telescopic insulating measuring pole 8 elements / Cover HPPOLE/190 / Max operating voltage cond. dry 900 kV
PPOL9/120MU / Number of element 9 / Folded length (m) 1,78 / Length unfolded (m) 12 / Telescopic insulating measuring pole 9 elements / Cover HPPOLE/190 / Max operating voltage cond. dry 900 kV
