TM92N 1000 A TRMS AC+DC multimeter clamp

STANDARD(S) : IEC 61010 1000V CAT IV & CAT III

USE : To deal with the highest level of low-voltage electrical installations, the TM92N has a high protection rating and is ideal for maintenance, testing, monitoring and diagnostics on medium-power installations.

SPECIFICATIONS :
Clamping diameter : 48 mm
Current : 1,000 A AC / 1,500 A DC
AC and DC voltage up to 1000 V
Resistance and audible continuity
Power values (W, var, VA, PF) and harmonics (THDf, THDr)
"2-wire method" phase rotation
Automatic AC/DC detection
True Inrush current measurement
Min, MAX, Peak+, Peak-
Relative (ΔX) and differential (ΔX/X) measurements
CAT IV 1,000 V
IP54 protection rating

ADVANTAGES : Equipped with a fast 12-bit TRMS digital acquisition system, TM92N clamps offer particularly accurate measurements whatever the signal's waveform.
