TM17 5 kV megohmmeter

STANDARD(S) : IEC 61010 1000 V CAT III safety

USE :
The TM17 makes industrial equipment inspection and maintenance testing particularly simple.
In its site-proof casing suitable for even the severest conditions, the TM17 offers optimum accuracy and expertise for insulation testing.
As soon as it is connected, it measures the voltage, frequency, capacitance and residual current values on the installation or equipment to be tested.

SPECIFICATIONS :
Power supply : Rechargeable NiMH battery
Large measurement range from 10 kΩ to 10 TΩ
Large backlit LCD screen, with digital display and bargraph
Fixed test voltages and programmable test voltages from 40 V to 5100 V
Automatic calculation of the DAR / PI /DD quality ratios
Voltage, capacitance and leakage current
Highly shock-resistant leakproof cover (IP 53)
Delivered with a carrying bag containing:
- 2 simplified measurement leads 2 m long, equipped with an HV plug at each end (red / blue)
- 1 guarded safety lead 2 m long, equipped with an HV plug at one end and an HV plug with rear connection at the other end (black)
- 1 guarded safety lead 0.35 m long, equipped with an HV plug at one end and an HV plug with rear connection at the other end (blue)
- 3 alligator clips (red, blue and black)
- 1 mains power cable 1.80 m long
- 1 operating manual in 5 languages

ADVANTAGES :
Single button: ease of use
