GasPro PID VOC Gas Detector (Diffusion)
The Gas-Pro PID VOC gas detector gives you full flexibility to monitor a wide range of gas types and volatile organic compounds (VOCs). With an optional pump, the Gas-Pro PID is the perfect product addressing the requirements of a wide range of applications.
Overview
The Gas-Pro PID VOC monitor utilises the Photo Ionization Detection technology to allow you to detect hundreds of Volatile Organic Compounds (VOCs). If you are working in an environment that is high in levels of solvents, glues, paints and general VOCs, the Gas-Pro PID will monitor your safety. With its dual-coloured display, the monitor will alert the user with its 95db audible alarm and its dual-coloured visual alarm bars.
PID Technology
Crowcon’s PID works with a 10.6 electron volt lamp. This sensor is the most stable sensor on the market and offers the detection of a wide range of VOCs. The sensor has an internal UV light source, which the gas sample passes through. An electron is released for gases with an ionization potential of 10.6.
User Friendly
Top Mount Display – makes it easy to read at a glance
Simple Single Button Operation – can be used whilst wearing gloves
Intuitive Functionality – reduces training time
Adaptable
Monitor 5 Gases In Many Different Combinations
Pumped And Diffusion Solutions – offers multiple uses within one compact detector
Multiple Languages
Automatic Fail-Safe Flow Plate Recognition – takes away the pain of pre-entry testing
Specific And Unique Pre-Entry Check (PEC) Mode
Reliable
Reliable Lithium-Ion Battery – provides over 14 hr use from a 7.5 hr charge
Water And Dust Resistant To IP65 And IP67 – capable of withstanding harsh environments
Bump And Calibration Reminders – Full compliance
Specifications
Size	43 x 130 x 84mm (1.7 x 5.1 x 3.3ins)
Weight	309g 4 gas (10.8oz)/ 340g pumped (11.9oz)
333g 5 gas (11.7oz)/ 362g pumped (12.7oz)
Alarms	Audible >95dB @ 30cm (98dB @30cm in loud mode)
Visual – all angle dual red/blue LEDs
Vibrating alert
Display	Top mount for ease of view with dual colour backlight (green/red)
Data logging	125 hr at 10-second intervals (45,000 logs)
Event logging	Alarm, over range, calibration, bump, on/off, TWA, 1000 events
Battery	Rechargeable Li-ion, >14 hr (13 hr pumped operation) based on CH4, O2, H2S, CO
Typical charge time 7.5 hr
Sampling	Internal pump as option
Operating temperature	-20°C to +55°C (-4°F to +131°F)
Storage	-20°C to +65°C (-4°F to +149°F)
Humidity	10 to 95% RH
Ingress protection	Independently tested to IP65
Approvals	IECEx: Ex db ia IIC T4 Gb Tamb -20°C to +55°C
ATEX: II 2 G Ex db ia IIC T4 Gb Tamb -20°C to +55°C
UL: Class 1, Division 1, Groups A, B, C, and D UL 913, UL 60079-0 and UL 60079-11
INMETRO: Ex db ia IIC T4 Gb Tamb -20°C to +55°C
Marine Equipment Directive: MED 1500009
Compliance	FCC and CE
Complies with EMC Directive 2014/30/EU
EN50270 and ICES-003
Interface	Data connection for gas test solutions and direct to PC
Charging	Direct connection to multiregional power supply
Vehicle charger adaptor
Desktop cradle
USB power and communications lead
Crowcon Connect Compatible?	Yes
Gases and Ranges
Gas	Range	Typical Alarms	Resolution
PID	 0-1000ppm	 50ppm	 1ppm
Ammonia (NH3)	 0-100ppm	 25ppm	 1ppm
Ammonia (NH3)	 0-1000ppm	 N/A	 1ppm
Carbon dioxide (CO2)	 0-5% vol.	 0-5% vol.	 0.01% vol.
Carbon monoxide (CO)	 0-2000ppm	 30ppm	 1ppm
Carbon monoxide (CO)	 0-500ppm	 30ppm	 1ppm
Carbon monoxide (hydrogen filtered)	 0-2000ppm	 30ppm	 1ppm
Chlorine (Cl2)	 0 – 5ppm	 0.5ppm	 0.1ppm
Dual toxic (CO-H2S)
H2S 0-100ppm 30ppm	 1ppm
CO 0-500ppm	 5ppm 1ppm
Flammable	 0-100% LEL	 20% LEL	 1% LEL
Hydrogen (H2)	 0-1000ppm	 N/A	 1ppm
Hydrogen sulphide (H2S)	 0-100ppm	 5ppm	 1ppm
Nitrogen dioxide (NO2)	 0-20ppm	 1ppm	 0.5ppm
Oxygen (O2)	 0-25% vol.	 19.5% / 23.5% vol.	 0.1% vol.
Ozone (O3)	 0-1ppm	 0.1ppm	 0.01ppm
Sulpher dioxide (SO2)	 0-20ppm	 1ppm	 0.1ppm
Chlorine dioxide (ClO2)	 0-1ppm	 0.1ppm	 0.1ppm
Nitric oxide (NO)	 0-100ppm	 25ppm	 1ppm
Gas-Pro PID sensor is calibrated to Isobutylene. Correction factors for other VOCs can be configured using Portables Pro PC software.
Standard alarm levels are applied per region/country and may be reconfigured using Portables Pro PC software.
| GasPro Config 6) Charging/USB Communication Cables | A Multi-region power supply or C Gas-Pro Charger cradle with supply or D USB communication lead (no power) or Z None |
| GasPro Config 7) Sensors Bay 1 | ZZ None or DA-DB Dual Toxic CO 0-500ppm/H2S 0-100ppm or AL Hydrogen sulphide 0-100ppm or AT Hydrogen sulphide 0-1000ppm or AC Carbon monoxide 0-500ppm or AU Hydrogen cyanide 0-50ppm or AK Hydrogen 0-1000ppm or AQ Sulphur dioxide 0-20ppm (H2S filtered) or AA Ammonia 0-100ppm |
| GasPro Config 7) Sensors Bay 2 | FD Methane 0-100% LEL (pellistor) or FH Propane 0-100% LEL (pellistor) or FI Pentane 0-100% LEL (pellistor) or FG Butane 0-100% LEL (pellistor) or FC Ethylene 0-100% LEL (pellistor) or FM Acetylene 0-100% LEL (pellistor) |
| GasPro Config 7) Sensors Bay 4 | OC O2 0-25% vol. (3 year) or ZZ None |
| GasPro Config 7) Sensors Bay 3 | PA PID Sensor 0-1000ppm |
