Υποδοχές ανύψωσης τυμπάνου καλωδίων SFEPT

USE : Ideal to control efficiently the winding and unwinding of underground and overhead cables for networks installations.
Height adjustment made by independent manual hydraulic jack : easily adapt to level difference.
SPECIFICATIONS : Supplied with a spindle bar with brake.

SFEPT2 = 2 t cable drum lifting jacks , Drum diameter min/max (mm): 700 / 2000 , Drum width min/max (mm): 800 / 1300 , Dimensions (m): 1.4 x 0.6 x 0.55 (pour 1 chevalet) , Weight (kg): 180
SFEPT4 = 4 t cable drum lifting jacks , Drum diameter min/max (mm): 800 / 2800 , Drum width min/max (mm): 900 / 1400 , Dimensions (m): 1.8 x 0.6 x 0.55 (pour 1 chevalet) , Weight (kg): 230
SFEPT7 = 7 t cable drum lifting jacks , Drum diameter min/max (mm): 1000 / 2800 , Drum width min/max (mm): 1000 / 1500 , Dimensions (m): 2 x 0.6 x 0.55 (pour 1 chevalet) , Weight (kg): 280
SFEPT10 = 10 t cable drum lifting jacks , Drum diameter min/max (mm): 1500 / 3200 , Drum width min/max (mm): 1150 / 1650 , Dimensions (m): 2.2 x 0.6 x 0.55 (pour 1 chevalet) , Weight (kg): 500
