PSM Upper element PSM for insulating stick PXV
STANDARD(S) : IEC 60855-1 / EN 50508
USE : All weather use.
- No-voltage testing.
- Earthing on MV/LV lines and substations.
- Disconnector operation.
- All work involving medium mechanical loads.
SPECIFICATIONS :
Made up of 1, 2, 3 or 4 sections with :
• Fibreglass composite tube, Ø 32 mm, polyurethane foam-filled, compliant with IEC 60855 (series tested against penetration of humidity).
• Longitudinal dielectric strength 100 kV/30 cm guaranteed in humid atmosphere.
• Screw connectors ref. S37, light alloy.
• Elastomer hand guard marks the gripping zone.
PVX sticks are supplied off the shelf with these end fittings:
- U : notched universal
- APV : multi-purpose, 12 mm 6-sided with automatic locking
- B : bayonet.
- others : on request.
Please specify when ordering.
ADVANTAGES : Ribbed non-slip shaft.
TABLE LEGEND : * Add the end fitting code at the the end of the reference.
PSM100* = Overall length (m): 1 , Insulating length (mm): 850
PSM150* = Overall length (m): 1.5 , Insulating length (mm): 1385
PSM188* = Overall length (m): 1.88 , Insulating length (mm): 1730
PSM200* = Overall length (m): 2 , Insulating length (mm): 1850
PSM250* = Overall length (m): 2.5 , Insulating length (mm): 2350
PSM300* = Overall length (m): 3 , Insulating length (mm): 2850
