Εύκαμπτα χάλκινα καλώδια γείωσης και βραχυκυκλώματος

STANDARD(S) : IEC / EN 61138

USE : Cable for portable earthing and short-circuiting devices according to IEC 61230 (EN 61230).

SPECIFICATIONS :
TSC type : extra flexible PVC sheathed copper cable (ST11) for use from -25°C to +55°C.
SX type : silicone sheathed copper cable for use from -40°C to + 70°C.

TSC16 = Cable cross-section: 16 mm² , Ø over copper core: 5 mm , Cable heats up to 350°C at end of s/c: 4 kA/0.5s - 3 kA/1s , Cable heats up to 700°C at end of s/c: 6 kA/0.5s - 4 kA/1s , Item n° with silicone sheath: SX016 , Weight (g): 160
TSC25 = Cable cross-section: 25 mm² , Ø over copper core: 6.4 mm , Cable heats up to 350°C at end of s/c: 6.5 kA/0.5s - 4.5 kA/1s , Cable heats up to 700°C at end of s/c: 9.5 kA/0.5s - 6.5 kA/1s , Item n° with silicone sheath: SX025 , Weight (g): 300
TSC35 = Cable cross-section: 35 mm² , Ø over copper core: 8.2 mm , Cable heats up to 350°C at end of s/c: 9.5 kA/0.5s - 6.5 kA/1s , Cable heats up to 700°C at end of s/c: 13 kA/0.5s - 10.5 kA/1s , Item n° with silicone sheath: SX035 , Weight (g): 350
TSC40 = Cable cross-section: 40 mm² , Ø over copper core: 8.2 mm , Cable heats up to 350°C at end of s/c: 10.5 kA/0.5s - 7.5 kA/1s , Cable heats up to 700°C at end of s/c: 15 kA/0.5s - 9 kA/1s , Item n° with silicone sheath: / , Weight (g): 350
TSC50 = Cable cross-section: 50 mm² , Ø over copper core: 9.2 mm , Cable heats up to 350°C at end of s/c: 13 kA/0.5s - 9.5 kA/1s , Cable heats up to 700°C at end of s/c: 18.5 kA/0.5s - 13 kA/1s , Item n° with silicone sheath: SX050 , Weight (g): 550
TSC70 = Cable cross-section: 70 mm² , Ø over copper core: 12 mm , Cable heats up to 350°C at end of s/c: 18.5 kA/0.5s - 13 kA/1s , Cable heats up to 700°C at end of s/c: 26 kA/0.5s - 18.5 kA/1s , Item n° with silicone sheath: SX070 , Weight (g): 750
TSC75 = Cable cross-section: 75 mm² , Ø over copper core: 12.2 mm , Cable heats up to 350°C at end of s/c: 20 kA/0.5s - 14 kA/1s , Cable heats up to 700°C at end of s/c: 28 kA/0.5s - 20 kA/1s , Item n° with silicone sheath: / , Weight (g): 800
TSC95 = Cable cross-section: 95 mm² , Ø over copper core: 13 mm , Cable heats up to 350°C at end of s/c: 25 kA/0.5s - 18 kA/1s , Cable heats up to 700°C at end of s/c: 35.5 kA/0.5s - 25 kA/1s , Item n° with silicone sheath: SX095 , Weight (g): 980
TSC120 = Cable cross-section: 120 mm² , Ø over copper core: 14.8 mm , Cable heats up to 350°C at end of s/c: 31.5 kA/0.5s - 22.5 kA/1s , Cable heats up to 700°C at end of s/c: 45 kA/0.5s - 31.5 kA/1s , Item n° with silicone sheath: SX120 , Weight (g): 1305
TSC150 = Cable cross-section: 150 mm² , Ø over copper core: 18 mm , Cable heats up to 350°C at end of s/c: 40 kA/0.5s - 28 kA/1s , Cable heats up to 700°C at end of s/c: 56 kA/0.5s - 40 kA/1s , Item n° with silicone sheath: SX150 , Weight (g): 1620
TSC10 = Cable cross-section: 10 mm² , Ø over copper core: 4 mm , Cable heats up to 350°C at end of s/c: 2.6 kA/0.5s - 1.9 kA/1s , Cable heats up to 700°C at end of s/c: 3.7 kA/0.5s - 2.6 kA/1s , Item n° with silicone sheath: / , Weight (g): 100
